Free shipping 100% original motherboard for Gigabyte GA-X58A-UD3R 1366 pin X58 Desktop mainboards support USB3 SATA3 L5639 L5520

Quality: it is used, 100% tested full work before shipping !

Gigabyte GA-X58A-UD3R detailed parameters



Motherboard chipset

    Integrated chip sound card / card
    Chip maker Intel
    Main Chipset Intel X58
    Description Chipset Intel X58 + ICH10R Southbridge chipset Northbridge
    No graphics chips
    Audio chip integrated Realtek ALC889 8-channel audio chip
    NIC chip onboard Realtek RTL8111E Gigabit Ethernet

Processor Specifications

    Intel CPU platform
    CPU Type Core i7
    CPU socket LGA 1366
    CPU description supports LGA Nehalem Bloomfield 1366 interface Core i7 quad-core processor
    Support CPU number 1
    Board bus QPI support 4.8GT / s, 6.4GT / s

Memory Specifications

    Memory Type DDR3
    ×DDR3 DIMM     ">6 × DDR3 DIMM memory slots
    The maximum memory capacity of 24GB
    Memory description support for triple-channel DDR3 2200/1333/1066 / 800MHz Memory

Expansion slots

    ×PCI-E X16(2X16,2X8)     ">PCI-E slot 4 × PCI-E X16 graphics slot (2 X16,2 strip X8)
    ×PCI-E X1     ">2 × PCI-E X1 slots
    ×PCI     ">PCI slots 1 × PCI slot
    ×IDE     ">IDE slot 1 × IDE slot
    ×FDD,     ">FDD slot 1 × FDD, floppy drive
    ×SATA II;2×SATA III ">SATA Interface 8 × SATA II interfaces; 2 × SATA III Interface

I / O Interface

    ×USB2.0(4+6);2×USB3.0     ">10 × USB2.0 Interface USB Interface (4 +6 built back); 2 × USB3.0 Interface
    PS / 2 interfaces PS / 2 mouse, PS / 2 keyboard connector
    ×RJ45     ">Other interfaces 1 × RJ45 network interface
    ×eSATA     ">2 × eSATA Interface
    ×1394     ">1 × 1394 Interface
    ×     ">1 × coaxial output interfaces
    ×     ">1 × optical interface
    ×CMOS     ">1 × Clear CMOS button
    Audio Interface

Plate

    Mainboard ATX form
    ×24.4cm ">Dimensions 30.5 × 24.4cm

Software Management

    BIOS 2 16Mbit flash performance
    Use of licensed AWARD BIOS
    DualBIOS support
    PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Other parameters

    Multi-graphics technology support 2-Way / 3-Way ATI CrossFireX / NVIDIA SLI technology
    An 8-pin power connector, a 24-pin power connector
    12-phase power supply mode
    SATAII to support RAID 0,1,5,10 RAID function
    SATAIII support for RAID 0,1, JBOD
    Hardware Monitoring System voltage detection
    CPU / Northbridge temperature detection
    CPU / System / Power fan speed detection
    CPU overheating warning
    CPU fan fail warning
    CPU / system fan speed control
